GL Series - Horizontal flat-bed lathes
Hydrodynamic guiding
GURUTZPE GLX models feature four self-centering V-guides and inverted V-guide technology, allowing for single-setup machining.
The machine has 4 guides in two separate areas, one for the tool carriage and another for the tailstock and steady rests. The machine is therefore capable of machining the piece in a single setup, allowing the tool to cross the steady rest without stopping.
All this results in considerable savings by reducing processes and cycle times.
| GLX 13 | GLX 16 | GLX 20 | ||||
|---|---|---|---|---|---|---|
| MACHINING AREA | ||||||
| Swing over bed | Sob | mm | ∅ 1300 | ∅ 1600 | ∅ 2000 | |
| Swing over carriage | Soc | mm | ∅ 1000 | ∅ 1300 | ∅ 1700 | |
| Distance between points | Lbc | m | ≤ 15 | ≤ 15 | ≤ 20 | |
| HEADSTOCK | ||||||
| Motor power S1/S6 | Pm | kW | 28/34 [39/48] | 39/48 [51/65] | 71/88 [92/114] | |
| Motor torque S1/S6 | Tm | kNm | 5,3/6,5 [7,4/9,2] | 11,2/13,7 [13,8/17,6] | 24,4/30,2 [31,2/38,7] | |
| Range of speeds | ns | rpm | 0÷1000* | 0÷800* | 0÷500* | |
| Bar throughput | ∅sb | mm | - | - | - | |
| TAILSTOCK | ||||||
| Part weight e.p. | Wbc | t | ≤ 12 | ≤ 18 | ≤ 25 | |
| GLX 13 | GLX 16 | GLX 20 | ||||
|---|---|---|---|---|---|---|
| MACHINING AREA | ||||||
| Swing over bed | Sob | in | Ø 51.18 | Ø 63.00 | Ø 78.74 | |
| Swing over carriage | Soc | in | Ø 39.37 | Ø 51.18 | Ø 66.93 | |
| Distance between points | Lbc | ft | ≤ 49.21 | ≤ 49.21 | ≤ 65.62 | |
| HEADSTOCK | ||||||
| Motor power S1/S6 | Pm | hp | 37/45.63 [52.27/63.36] | 52.27/63.36 [68.79/87.72] | 95.46/116.96 [120.85/149.72] | |
| Motor torque S1/S6 | Tm | lbf-ft | 39.12/47.92 [54.56/68.05] | 83.00/101.27 [97.61/129.34] | 242.39/299.37 [250.88/309.55] | |
| Range of speeds | ns | rpm | 0-1000* | 0-800* | 0-500* | |
| Bar throughput | ∅sb | in | - | - | - | |
| TAILSTOCK | ||||||
| Part weight e.p. | Wbc | lb | ≤ 26.46 | ≤ 39.68 | ≤ 55.12 | |
GURUTZPE solutions allow the user to focus the machine’s functions on specific operational needs, guaranteeing an optimal return on investment. We are always ready to work alongside customers for any special and complex challenge put to us.
In addition to the regular components that make up the machine, GURUTZPE has a wide range of accessories and technologies that enable and facilitate critical machining operations on the part.
